LDLN025M45R 4.5V 250mA LDO SOT-23-5 Entegre Devre
31,37 TL
3,28 TL den başlayan taksitlerle!
0 Puan / 0 Yorum
Kategori
Marka
Stok Kodu
LDLN025M45R
Stok Adedi
1
Fiyat
0,58 USD + KDV
STMicroelectronics LDLN025M45R, 5.5V’a kadar girişten 4.5V sabit pozitif çıkış veren 250mA lineer regülatör (LDO) entegresidir. SOT-23-5 (SC-74A/SOT-753) SMD kılıfta, enable pini bulunur ve tipik 25µA düşük boşta akım değerine sahiptir. Aşırı akım, aşırı sıcaklık ve kısa devre korumaları ile soft-start desteği içerir.
LDLN025M45R IC REG LINEAR 4.5V 250MA SOT23-5
| Ürün Kodu | LDLN025M45R |
| Control Features | Enable |
| Current - Output | 250mA |
| Current - Quiescent (Iq) | 25 µA |
| Current - Supply (Max) | 425 µA |
| Mounting Type | Surface Mount |
| Number of Regulators | 1 |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Output Configuration | Positive |
| Output Type | Fixed |
| Package / Case | SC-74A, SOT-753 |
| Part Status | Active |
| Protection Features | Over Current, Over Temperature, Short Circuit, Soft Start |
| PSRR | 80dB ~ 60dB (100Hz ~ 100KHz) |
| Supplier Device Package | SOT-23-5 |
| Voltage - Input (Max) | 5.5V |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 4.5V |
| Voltage Dropout (Max) | 0.2V @ 250mA |
