Görseller temsilidir, tam özellikler için datasheet'e bakınız.
TPS7A2050PDQNR 5V 300mA 4-X2SON (1x1) Entegre Devre
TPS7A2050PDQNR
- Üretici
- Texas Instruments
- Kategori
- Kılıf / Paket
- —
TPS7A2050PDQNR 5V 300mA 4-X2SON (1x1) Entegre Devre Hakkında
Texas Instruments TPS7A2050PDQNR, 5V sabit çıkışlı 300mA LDO voltaj regülatörüdür. 15 µA düşük boşta akım, düşük gürültü ve Enable kontrol girişine sahiptir. 6V maksimum giriş, 0.14V dropout (300mA) ve aşırı akım/sıcaklık ile UVLO korumaları sunar.
TPS7A2050PDQNR 300-MA, ULTRA-LOW-NOISE, LOW-IQ,
| Ürün Kodu | TPS7A2050PDQNR |
| Control Features | Enable |
| Current - Output | 300mA |
| Current - Quiescent (Iq) | 15 µA |
| Current - Supply (Max) | - |
| Mounting Type | Surface Mount |
| Number of Regulators | 1 |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Output Configuration | Positive |
| Output Type | Fixed |
| Package / Case | 4-XDFN Exposed Pad |
| Part Status | Active |
| Protection Features | Over Current, Over Temperature, Under Voltage Lockout (UVLO) |
| PSRR | 65dB ~ 40dB (100Hz ~ 1MHz) |
| Supplier Device Package | 4-X2SON (1x1) |
| Voltage - Input (Max) | 6V |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 5V |
| Voltage Dropout (Max) | 0.14V @ 300mA |
TPS7A2050PDQNR Datasheet dosyasına ulaşmak için tıklayınız.
