TMUX4052PWRQ1 Texas Instruments 16-TSSOP Entegre Devre
57,17 TL
5,98 TL den başlayan taksitlerle!
0 Puan / 0 Yorum
Kategori
Marka
Stok Kodu
TMUX4052PWRQ1
Stok Adedi
0
Fiyat
1,06 USD + KDV
TMUX4052PWRQ1, Texas Instruments üretimi 16-TSSOP kılıfta 2 devreli 4:1 analog multiplexer/demultiplexer anahtar entegresidir. 5V–24V tek besleme ile çalışır, maksimum 240Ω iletim direncine sahiptir ve -55°C ile 125°C aralığında kullanılabilir. Otomotiv sınıfıdır ve AEC-Q100 kalifikasyonuna uygundur.
TMUX4052PWRQ1 16-TSSOP (0.173", 4.40mm Width) kılıfta üretilmiştir. 2 Circuit IC Switch 4:1 240Ohm 16-TSSOP
| Ürün Kodu | TMUX4052PWRQ1 |
| Switch Circuit | SP4T - Open |
| Multiplexer/Demultiplexer Circuit | 4:1 |
| Number of Circuits | 2 |
| On-State Resistance (Max) | 240Ohm |
| Channel-to-Channel Matching (ΔRon) | 2Ohm |
| Voltage - Supply, Single (V+) | 5V ~ 24V |
| Voltage - Supply, Dual (V±) | - |
| Switch Time (Ton, Toff) (Max) | 110ns, 85ns (Typ) |
| -3db Bandwidth | 700MHz |
| Charge Injection | - |
| Channel Capacitance (CS(off), CD(off)) | 3pF, 5pF |
| Current - Leakage (IS(off)) (Max) | - |
| Crosstalk | -90dB @ 1MHz |
| Operating Temperature | -55°C ~ 125°C (TA) |
| Grade | Automotive |
| Qualification | AEC-Q100 |
| Mounting Type | Surface Mount |
| Package / Case | 16-TSSOP (0.173", 4.40mm Width) |
| Supplier Device Package | 16-TSSOP |
TMUX4052PWRQ1 Datasheet dosyasına ulaşmak için tıklayınız.
