Texas Instruments DRV8703QRHBTQ1 Motor Sürücü Entegre Devre
DRV8703QRHBTQ1
- Üretici
- Texas Instruments
- Kategori
- Kılıf / Paket
- —
Texas Instruments DRV8703QRHBTQ1 Motor Sürücü Entegre Devre Hakkında
Texas Instruments DRV8703QRHBTQ1, fırçalı DC motor uygulamaları için tam entegre kontrol ve güç katı içeren motor sürücü entegresidir. 5.5V-45V besleme aralığında çalışır, PWM arayüzünü destekler ve 32-VQFN (5x5) kılıfta sunulur. Çalışma sıcaklığı aralığı -40°C ile 150°C (TJ) arasındadır.
DRV8703QRHBTQ1 IC MOTOR DRIVER 5.5V-45V 32VQFN
| Ürün Kodu | DRV8703QRHBTQ1 |
| Applications | Brushed DC |
| Current - Output | - |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Interface | PWM |
| Motor Type - AC, DC | Brushed DC |
| Motor Type - Stepper | - |
| Mounting Type | Surface Mount, Wettable Flank |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Output Configuration | Half Bridge (2) |
| Package / Case | 32-VFQFN Exposed Pad |
| Part Status | Active |
| Step Resolution | - |
| Supplier Device Package | 32-VQFN (5x5) |
| Technology | Power MOSFET |
| Voltage - Load | - |
| Voltage - Supply | 5.5V ~ 45V |
DRV8703QRHBTQ1 Datasheet dosyasına ulaşmak için tıklayınız.
